煤矿井下钢丝绳输送带主要技术参数(MT668)
|
项目 |
St
630 |
St
800 |
St
1000 |
St
1250 |
St
1600 |
St
2000 |
St
2500 |
St
3150 |
St
3500 |
St
4000 |
St
4500 |
St
5000 |
St
5400 |
|
纵向拉伸强度，N/mm |
630 |
800 |
1000 |
1250 |
1600 |
2000 |
2500 |
3150 |
3500 |
4000 |
4500 |
5000 |
5400 |
|
钢丝绳最大公称直径 mm |
3.0 |
3.5 |
4.0 |
4.5 |
5.0 |
6.0 |
7.2 |
8.1 |
8.6 |
8.9 |
9.7 |
10.9 |
11.3 |
|
钢丝绳间距，1.
|
10 |
10 |
12 |
12 |
12 |
12 |
15 |
15 |
15 |
15 |
16 |
17 |
17 |
|
上覆盖层厚度，mm |
5 |
5 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8 |
8 |
8.5 |
9 |
|
下覆盖层厚度，mm |
5 |
5 |
6 |
6 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8.5 |
9 |
|
参考质量 |
21 |
22 |
27 |
29 |
31 |
37 |
42.5 |
49 |
51 |
52.5 |
58.5 |
63 |
68 |
|
宽度规格 mm |
钢丝绳根数 |
||||||||||||
|
800 |
75 |
75 |
63 |
63 |
63 |
63 |
50 |
50 |
50 |
|
|
|
|
|
1000 |
95 |
95 |
79 |
79 |
79 |
79 |
64 |
64 |
64 |
64 |
59 |
55 |
55 |
|
1200 |
113 |
113 |
94 |
94 |
94 |
94 |
76 |
76 |
77 |
77 |
71 |
66 |
66 |
|
1400 |
133 |
133 |
111 |
111 |
111 |
111 |
89 |
89 |
90 |
90 |
84 |
78 |
78 |
|
1600 |
151 |
151 |
126 |
126 |
126 |
126 |
101 |
101 |
104 |
104 |
96 |
90 |
90 |
|
1800 |
|
171 |
143 |
143 |
143 |
143 |
114 |
114 |
117 |
117 |
109 |
102 |
102 |
|
2000 |
|
|
159 |
159 |
159 |
159 |
128 |
128 |
130 |
130 |
121 |
113 |
113 |
|
2200 |
|
|
|
|
|
176 |
141 |
141 |
144 |
144 |
134 |
125 |
125 |
